With the OPTIMA machine system, cutting orders are completed in minimal time and with minimal efforts. The OPTIMA is the most cost-effective automated sheet metal cutting machine on the market.
A number of optional functions allow for a wide range of applications.
STURDY – COMPACT – SIMPLE
- easy to use
- robust
- simple construction
- reliable and efficient
- ideally configured software and hardware
- intuitive and user-friendly operation
- useful machine control functions
- lowest priced slitting machine on the market with automatic knife adjustment
- high quality
- fully automatic slitting knife positioning (ergonomic, fast, reliable)
- many options to choose from (partial cross cut, film application, labeling, etc.)
- electronic order management possible
ROBUST - COMPACT – SIMPLE
- easy to use
- robust
- simple construction
- reliable and efficient
- ideal configured software and hardware
- intuitive and user-friendly operation
- useful machine control functions
- lowest priced slitting machine on market with automatic knife adjustment
- high quality
- fully automatic slitting knife positioning (ergonomic, fast, reliable)
- many options to choose from (partial cross cut, film application, labeling,…)
- electronic order management possible
Technical specification
max. sheet metal width (coil / sheet) | 1,250 mm / 49“ |
min. sheet metal width (coil / sheet) | 250 mm / 10“ |
sheet metal thickness | 0.4 – 1.25 mm* / |
sheet metal thickness stainless | 0.4 – 0.9 mm* / |
sheet metal thickness | 0.5 – 1.5 mm* / |
minimum sheet metal strip width | 60 mm / 2.4“ (knife / knife) |
straightening unit | 3 straightening rolls, |
maximum cutting speed | 30 m / min |
cutting accuracy | class "m" DIN/ISO 2768 |
slitting (longitudinal cut) | up to 8 slitting knife pairs |
cutting (transverse cut) | guillotine shear or |
film application | manuell (optional) |
label printing | manuell (optional) |
sheet metal feeding | metal sheets |
coil exchange time | depending on sheet metal feeding type |
maximum coil weight | depending on sheet metal feeding type |
small coil - / leftover coil processing | manual feeding |
maximum coil outside diameter | depending on sheet |
interface to recoiler | optional |
machine interface | OPTIMIZER-software (optional) |
*according to knife specification table
