Machine system comparison

1,250 mm / 49“

maximum sheet metal width
(coil / sheet)

1,250 mm / 49“
1,500 mm / 60“

250 mm / 10“

minimum sheet metal width
(coil / sheet)

250 mm at 1,250  /  10” at 49”
400mm at 1,500 / 15.7” at 60”

0.4 – 1.25 mm* /
29 - 18ga*

sheet metal thickness steel up to 400 N/mm²

0.4 – 1.5 mm* /
27 - 16ga*

0.4 – 0.9 mm* /
28 - 22ga*

sheet metal thickness stainless steel up to 550 N/mm²

0.4 - 1 mm* /
28 - 20ga*

0.5 – 1.5 mm* /
0.02“/16oz*- 0.063“/48oz*

sheet metal thickness aluminum (AlMg3) and copper

0.5 - 2 mm* /
24“/14oz* - 12“/56oz*

60 mm / 2.4“ (knife / knife)
15 mm / 0.6” (edge strip)

minimum sheet metal strip width

75 mm / 3” (knife / knife)
15 mm / 0.6” (edge strip)

3 straightening rolls, swivelling (optional)

straightening unit (automatic, progressive)

5 roll or (optional) 7 roll straightening unit

30 m / min
110ft/min (adjustable)

maximum cutting speed

35 m / min
115ft/min (adjustable)

class "m" DIN/ISO 2768 (± 0.8 mm/m)
(± 1/100"/ft)

cutting accuracy

class "m" DIN/ISO 2768 (± 0.8 mm/m)
(± 1/100"/ft)

up to 8 slitting knife pairs
(0,5,6,7 or 8)

slitting (longitudinal cut)

up to 8 slitting knife pairs
(0,5,6,7 or 8)

guillotine shear or (optional) roller shear

cutting (transverse cut)

guillotine shear or (optional) roller shear

manual (optional)

film application

manual / automatic (both optional)

manual (optional)

label printing

manual / automatic (both optional)

metal sheets
coils on coil cart
coils on driven decoilers
coils from existing coil warehouse systems

sheet metal feeding

metal sheets
coils on coil carts
coils on driven decoilers
coils from 1-lane automatic coil warehouse
coils from multi-lane automatic coil warehouse (max. 5 lanes)

depending on sheet metal feeding type

coil exchange time

depending on application
< 2 min. at automatic coil warehouse

depending on sheet metal feeding type

maximum coil weight

depending on sheet metal feeding type
max 8 ton / 17,600 lbs at automatic coil warehouse

manual feeding

small coil - / leftover coil processing

manual feeding /
automatic with coil cage (optional)

depending on sheet metal feeding type

maximum coil outside diameter

depending on sheet metal feeding type
max 1.250 mm / 49” diameter

optional

interface to recoiler

optional

OPTIMIZER-software  (optional)
BENDEX
or others on request (optional)

machine interface and software interface

OPTIMIZER-software (optional)
BENDEX
or others on request (optional)
